Описание
Tavsif
Kirish kuchlanishi
Kirish tizimi: 3 faza (L1, L2, L3, N, PE) yoki 1 faza (L, N, PE)
Nominal kuchlanish: 208/220/230 / 240Vac
Chastotasi: 50Hz / 60Hz
Chastota diapazoni: （40~70)±0,5 Hz
Kuchlanish diapazoni: 156~520 VAC =5VAC (past kuchlanish)
Kirish quvvati koeffitsienti: >0,99
AC chiqishi
Chiqish signalini ulash tizimi: 1 fazali 3 sim (L, N, G)
Inverter rejimi chiqish kuchlanishi: 220/230 / 240vac±2%
Signal shakli: sinus to'lqin
Chiqish chastotasi: 50/60±4hz (Sync mode) 50 / 60Hz±1% (Fix Freq. mode)
O'tkazish vaqti: Line mode - > batareya rejimi 0ms
Aloqa porti: RS232 RS485 (ixtiyoriy), quruq aloqa (ixtiyoriy), tarmoq kartasi (ixtiyoriy)
Shovqin darajasi: 55dB
Himoya funktsiyasi: AC kirish yoki chiqish kuchlanish diapazonidan yuqori yoki past, haddan tashqari yuk, haddan tashqari issiqlik va qisqa tutashuvdan himoya
